Technical Specifications
FRAMESET
Frame
S-Works FACT 12m Carbon, Progressive XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing, 110mm of travel
Seat Binder
Specialized Alloy 34.9, Titanium Bolt
SUSPENSION
Rear Shock
RockShox SID LUXE ULTIMATE, Rx XC Tune, Two Position, Rebound Adjust, 190x40mm
Fork
Rockshox SID ULTIMATE, Charger Race Day Damper, Debon Air, 15x110mm, 44mm offset, 120mm Travel
COCKPIT
Stem
TruVativ Descendant 35, 35mm clamp, 60mm
Handlebars
Roval Control SL Rise, 780mm x 35mm, 20mm rise, Carbon
Tape
Specialized Trail Grips
Saddle
Body Geometry S-Works Power, carbon fiber rails, carbon fiber base
SeatPost
RockShox Reverb AXS, 30.9mm, S: 125, M:150, L/XL: 170mm
BRAKES
Front Brake
SRAM G2 Ultimate, 4-piston caliper, hydraulic disc, 180mm rotor
Rear Brake
SRAM G2 Ultimate, 4-piston caliper, hydraulic disc, 180mm rotor
DRIVETRAIN
Rear Derailleur
Sram XX1 Eagle AXS
Shift Levers
SRAM AXS Rocker Paddle
Cassette
SRAM XG-1299 10-52T Rainbow
Chain
SRAM XX1 Eagle
Crankset
SRAM XX1 Eagle Carbon, DUB, 170/175mm, 32T
Chainrings
Alloy, 32T
Bottom Bracket
SRAM DUB, BSA 73mm, Threaded
WHEELS
Rims
Roval Control SL, Carbon offset design, 29mm internal width, 4mm hook width, Tubeless ready, 24h
Front Hub
Roval Control SL, DT Swiss Internals, Ceramic Bearings, 6-bolt, 15mm thru-axle, 110mm spacing, Torque caps, 24h straight pull t-head
Rear Hub
Roval Control SL, DT Swiss 180 Internals, DT Swiss Ratchet EXP, Ceramic bearings, 12mm thru-axle, 148mm spacing, 24h straight-pull
Spokes
DT Swiss Aerolite T-head
Front Tire
Specialized Ground Control, Control Casing, T5 Compound, 29x2.35
Rear Tire
Specialized Ground Control, Control Casing, T5 Compound, 29x2.35
Inner Tubes
Specialized Turbo Tube
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
S | M | L | XL | |
---|---|---|---|---|
Crank Length | 170mm | 175mm | 175mm | 175mm |
Handlebar Width | 760mm | 760mm | 760mm | 760mm |
Stem Length | 60mm | 60mm | 60mm | 60mm |
Saddle Width | 155mm | 143mm | 143mm | 143mm |
Seatpost Length | 125mm | 125mm | 150mm | 170mm |
Stack | 593mm | 597mm | 611mm | 629mm |
Reach | 406mm | 436mm | 460mm | 485mm |
Head Tube Length | 95mm | 100mm | 115mm | 135mm |
Head Tube Angle | 66.5° | 66.5° | 66.5° | 66.5° |
BB Height | 336mm | 336mm | 336mm | 336mm |
BB Drop | 36mm | 36mm | 36mm | 36mm |
Trail | 114mm | 114mm | 114mm | 114mm |
Fork Length, Full | 530mm | 530mm | 530mm | 530mm |
Fork Rake/Offset | 44mm | 44mm | 44mm | 44mm |
Front Center | 697mm | 729mm | 759mm | 792mm |
Chainstay Length | 438mm | 438mm | 438mm | 438mm |
Wheelbase | 1132mm | 1164mm | 1194mm | 1227mm |
Bike Standover Height | 779mm | 781mm | 793mm | 804mm |
Seat Tube Length | 400mm | 430mm | 470mm | 520mm |
Seat Tube Angle | 74.8° | 74.5° | 74.5° | 74.5° |
Top Tube Length, Horizontal | 567mm | 602mm | 629mm | 659mm |
