Technical Specifications
COCKPIT
Stem
Alloy Trail Stem, 35mm bar bore
Handlebars
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 800mm width
Tape
Specialized Trail Grips
Saddle
Bridge Comp, Hollow Cr-mo rails, 155/143mm
SeatPost
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9mm, S2: 125mm, S3/S4: 150mm, S5: 170mm
BRAKES
Front Brake
SRAM Code R, 4-piston caliper, hydraulic disc, 220mm
Rear Brake
SRAM Code R, 4-piston caliper, hydraulic disc, 200mm
DRIVETRAIN
Rear Derailleur
SRAM GX Eagle, 12-speed
Shift Levers
SRAM GX, trigger, 12-speed
Cassette
Sram XG-1275, 12-speed, 10-52t
Chain
SRAM NX Eagle, 12-speed
Crankset
Praxis Forged/M30 Spindle Interface
Chainrings
SRAM X-Sync Eagle, 94 BCD, 32T, alloy
WHEELS
Rims
Specialized 29, hookless alloy, 30mm inner width, tubeless ready
Front Hub
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Spokes
DT Swiss Industry
Front Tire
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
Inner Tubes
Standard, Presta valve
Rear Hub
Alloy, sealed cartridge bearings, 148mmx12mm thru-axle, 28h
Rear Tire
Butcher, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 29x2.3"
FRAMESET
Seat Binder
Alloy, 38.6mm
Frame
FACT 11m full carbon, 29", full internal cable routing, 148mm spacing, fully sealed cartridge bearings, 170mm rear travel, geo adjust head tube, geo adjust horst pivot
Fork
FOX FLOAT 36 RHYTHM 29, GRIP damper, 44mm offset, 2-position sweep adjust, 15x110mm, 1.5" tapered steerer, 170mm travel
E-BIKE
Motor
Specialized SL 1.1, custom lightweight motor
Battery
Specialized SL1-320, fully integrated, 320Wh
Charger
Custom charger, 48V System w/ SL system charger plug
UI/Remote
Specialized MasterMind TCU, ANT+/Bluetooth®, w/Handlebar remote
Wiring Harness
Custom Specialized wiring harness
SUSPENSION
Rear Shock
FOX FLOAT X Performance, LSR, 2-position lever, 62.5x230mm
ACCESSORIES
SWAT
SWAT CC, integrated tool and chain tool with spare link in steerer tube
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
S2 | S3 | S4 | S5 | |
---|---|---|---|---|
Crank Length | 165mm | 165mm | 170mm | 170mm |
Handlebar Width | 800mm | 800mm | 800mm | 800mm |
Stem Length | 40mm | 50mm | 50mm | 50mm |
Saddle Width | 155mm | 143mm | 143mm | 143mm |
Seatpost Length | 125 mm | 150 mm | 170 mm | 170 mm |
Stack | 618mm | 626mm | 635mm | 644mm |
Reach | 435mm | 460mm | 485mm | 510mm |
Headtube Length | 105mm | 115mm | 125mm | 135mm |
Headtube Angle | 63.5° | 63.5° | 63.5° | 63.5° |
BB Height | 350mm | 350mm | 350mm | 350mm |
BB Drop | 25mm | 25mm | 25mm | 25mm |
Trail | 136mm | 136mm | 136mm | 136mm |
Fork Length (full) | 579mm | 579mm | 579mm | 579mm |
Fork Rake/Offset | 46mm | 46mm | 46mm | 46mm |
Front Center | 782mm | 812mm | 841mm | 871mm |
Chainstay Length | 447mm | 447.3mm | 447mm | 447mm |
Wheelbase | 1228mm | 1258mm | 1287mm | 1316mm |
Bike Standover Height | 779mm | 779mm | 792mm | 802mm |
Seat Tube Length | 400mm | 420mm | 440mm | 465mm |
Seat Tube Angle | 76° | 76° | 76° | 76° |
Max Seatpost Insertion | 0mm | 0mm | 0mm | 0mm |
Min Seatpost Insertion | 80mm | 80mm | 80mm | 80mm |
Size Guide
-
