Technical Specifications
COCKPIT
Stem
Deity, 35.0mm
Handlebars
Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree backsweep, 30mm rise, 800mm, 35.0mm
Grips
Deity, Knuckleduster, Black
Saddle
Bridge, 155/143mm, Hollow Ti-rails
SeatPost
RockShox Reverb AXS, 30.9mm, S2: 125mm, S3: 150mm, S4/S5: 170mm
BRAKES
Front Brake
SRAM Code RSC, 4-piston caliper, hydraulic disc, 220mm
Rear Brake
SRAM Code RSC, 4-piston caliper, hydraulic disc, 200mm
DRIVETRAIN
Rear Derailleur
SRAM XX1 Eagle AXS
Cassette
SRAM XG-1299 Eagle, 10-52t
Chain
SRAM XX1, 12 speed
Shift Levers
SRAM Eagle AXS Rocker Paddle
Crankset
Praxis Carbon/M30 Spindle Interface
Chainrings
SRAM X-Sync Eagle, 94 BCD, 32T, alloy
WHEELS
Front Tire
Butcher Grid Trail T9 29x2.3"
Inner Tubes
Standard, Presta valve
Rear Tire
Butcher Grid Trail T7 29 x 2.3"
E-BIKE
Motor
Specialized SL 1.1, custom lightweight motor
Battery
Specialized SL1-320, fully integrated, 320Wh
Charger
Custom charger, 48V System w/ SL system charger plug
UI/Remote
Specialized MasterMind TCU, ANT+/Bluetooth®, w/Handlebar remote
Wiring Harness
Custom Specialized wiring harness
FRAMESET
Frame
FACT 11m full carbon, 29", full internal cable routing, 148mm spacing, fully sealed cartridge bearings, 170mm rear travel, geo adjust head tube, geo adjust horst pivot
Fork
FOX FLOAT 38 Factory 29, Grip2 damper, 44mm offset, HSC, LSC, HSR, LSR, 110x15mm, 1.5" tapered steerer, 170mm travel, Kashima
Seat Binder
Alloy, 38.6mm
Suspension
Rear Shock
FOX FLOAT X2 Factory, LSC, LSR, 2-position lever, 62.5x230mm, Kashima
ACCESSORIES
SWAT
SWAT CC, integrated tool and chain tool with spare link in steerer tube
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
S2 | S3 | S4 | S5 | |
---|---|---|---|---|
Crank Length | 165mm | 165mm | 170mm | 170mm |
Handlebar Width | 800mm | 800mm | 800mm | 800mm |
Stem Length | 35mm | 50mm | 50mm | 50mm |
Saddle Width | 155mm | 143mm | 143mm | 143mm |
Seatpost Length | 125mm | 150mm | 170mm | 170mm |
Stack | 618mm | 626mm | 635mm | 644mm |
Reach | 435mm | 460mm | 485mm | 510mm |
Headtube Length | 105mm | 115mm | 125mm | 135mm |
Headtube Angle | 63.5° | 63.5° | 63.5° | 63.5° |
BB Height | 350mm | 350mm | 350mm | 350mm |
BB Drop | 25mm | 25mm | 25mm | 25mm |
Trail | 136mm | 136mm | 136mm | 136mm |
Fork Length (full) | 579mm | 579mm | 579mm | 579mm |
Fork Rake/Offset | 46mm | 46mm | 46mm | 46mm |
Front Center | 782mm | 812mm | 841mm | 871mm |
Chainstay Length | 447mm | 447.3mm | 447mm | 447mm |
Wheelbase | 1228mm | 1258mm | 1287mm | 1316mm |
Bike Standover Height | 779mm | 779mm | 792mm | 802mm |
Seat Tube Length | 400mm | 420mm | 440mm | 465mm |
Seat Tube Angle | 76° | 76° | 76° | 76° |
Max Seatpost Insertion | 0mm | 0mm | 0mm | 0mm |
Min Seatpost Insertion | 80mm | 80mm | 80mm | 80mm |
Size Guide
-
