Technical Specifications
FRAMESET
Frame
S-Works Aethos FACT 12r Carbon, Rider First Engineered™, Threaded BB, Electronic cable routing only, 12x142mm thru-axle, flat-mount disc
SUSPENSION
Fork
S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc
COCKPIT
Handlebars
S-Works Short & Shallow, 125mm Drop, 75mm Reach w/Di2 Hole
Stem
S-Works SL, alloy, titanium bolts, 6-degree rise
Tape
Supacaz Super Sticky Kush
Saddle
Body Geometry S-Works Power, carbon fiber rails, carbon fiber base
SeatPost
Roval Alpinist Carbon Seatpost
Seat Binder
Specialized Alloy, 30.0mm, titanium bolt
BRAKES
Front Brake
SRAM Red eTAP AXS, hydraulic disc
Rear Brake
SRAM Red eTAP AXS, hydraulic disc
DRIVETRAIN
Shift Levers
SRAM Red eTap AXS
Front Derailleur
SRAM RED eTAP AXS, braze-on
Rear Derailleur
SRAM RED eTAP AXS, 12-speed
Cassette
SRAM RED XG-1290, 12-speed, 10-33t
Crankset
SRAM RED AXS Power Meter
Chainrings
48/35T
Bottom Bracket
SRAM DUB BSA 68
Chain
SRAM RED 12-speed
WHEELS & TIRES
Front Wheel
Roval Alpinist CLX, Tubeless, 21mm internal width carbon rim, 33mm depth, Win Tunnel Engineered, Roval AFD hub, 21h, DT Swiss Aerolite spokes
Rear Wheel
Roval Alpinist CLX, Tubeless, 21mm internal width carbon rim, 33mm depth, Win Tunnel Engineered, Roval AFD hub, 24h, DT Swiss Aerolite spokes
Front Tire
S-works Turbo 2BR, 700x28mm
Rear Tire
S-works Turbo 2BR, 700x28mm
Inner Tubes
700x20-28, 48mm Presta Valve
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
49 | 52 | 54 | 56 | 58 | 61 | |
---|---|---|---|---|---|---|
Crank Length | 165mm | 170mm | 172.5mm | 172.5mm | 175mm | 175mm |
Handlebar Width | 380mm | 400mm | 420mm | 420mm | 440mm | 440mm |
Stem Length | 80mm | 90mm | 100mm | 100mm | 110mm | 110mm |
Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm | 143mm |
Seatpost Length | 300mm | 300mm | 360mm | 360mm | 360mm | 360mm |
Stack | 514mm | 527mm | 544mm | 565mm | 591mm | 612mm |
Reach | 375mm | 380mm | 384mm | 395mm | 402mm | 408mm |
Head Tube Length | 109mm | 120mm | 137mm | 157mm | 184mm | 204mm |
Head Tube Angle | 71.75° | 72.5° | 73° | 73.5° | 73.5° | 74° |
BB Height | 266mm | 266mm | 268mm | 268mm | 268mm | 268mm |
BB Drop | 74mm | 74mm | 72mm | 72mm | 72mm | 72mm |
Trail | 63mm | 58mm | 58mm | 55mm | 55mm | 52mm |
Fork Length, Full | 369mm | 369mm | 369mm | 369mm | 369mm | 369mm |
Fork Rake/Offset | 47mm | 47mm | 44mm | 44mm | 44mm | 44mm |
Front Center | 574mm | 577mm | 579mm | 591mm | 606mm | 613mm |
Chainstay Length | 410mm | 410mm | 410mm | 410mm | 410mm | 410mm |
Wheelbase | 973mm | 975mm | 978mm | 991mm | 1005mm | 1012mm |
Top Tube Length, Horizontal | 508mm | 531mm | 540mm | 562mm | 577mm | 595mm |
Bike Standover Height | 705mm | 728mm | 748mm | 769mm | 796mm | 824mm |
Seat Tube Length | 431mm | 462mm | 481mm | 504mm | 532mm | 567mm |
Seat Tube Angle | 75.5° | 74° | 74° | 73.5° | 73.5° | 73° |
Size Guide
-
