Technical Specifications
FRAMESET
Frame
E5 Aluminum, bottom bracket motor mount, fully integrated &lockable downtube battery, internal cable routing, lock and front rack mount
Fork
SR Suntour XCM32, 110mm travel, lockout
Seat Binder
Alloy, bolt-type, 34.9mm
COCKPIT
Stem
Stout 3D-forged alloy, 31.8mm, 6-degree rise
Handlebars
Specialized Trail, 6061 alloy, 8-degree backsweep, 6-degree upsweep, 27mm rise, 31.8mm clamp, S 720mm, M-XL 750mm
Tape
Specialized Trail Grips, Lock-on
Saddle
Rivo Sport, steel rails, 155mm
SeatPost
Specialized, 6061 alloy, 2-bolt clamp, 0mm setback, 30.9mm
BRAKES
Front Brake
Shimano BR-MT200, hydraulic disc, 180mm
Rear Brake
Shimano BR-MT200, hydraulic disc, 180mm
DRIVETRAIN
Rear Derailleur
Shimano Alivio, SGS, 9-speed
Shift Levers
Shimano Alivio, 9-speed w/ Optical Gear Display
Cassette
Shimano CS-HG400, 9-speed, 11-36t
Chain
KMC e9T, 9-speed w/ Missing Link™
Crankset
Custom alloy forged crankarms
Chainrings
Praxis, 36T, 104BCD
ACCESSORIES
Pedals
Specialized platform pedal
Bell
Simple bell
WHEELS
Rims
Stout XC 29, 25mm internal width, disc-specific
Front Hub
Shimano MT400, Centerlock, 15x100mm, 32h
Rear Hub
Shimano MT400-B, Centerlock, 12x148 Boost, 32h
Spokes
DT Swiss Industry
Front Tire
Ground Control, 2Bliss Ready, 29x2.35"
Rear Tire
Ground Control, 2Bliss Ready, 29x2.35"
Inner Tubes
Presta, 48mm valve
E-BIKE
Motor
Specialized 2.0E, 50Nm torque, custom tuned motor, 250W nominal
UI/Remote
MasterMind TCD, w/handlebar remote, built-in anti-theft feature, Bluetooth® connectivity, customizable display pages
Battery
Specialized U2-530, alloy casing, state of charge display, 530Wh
Charger
Custom charger, 42V4A w/ Rosenberger plug, 100-240V
Wiring Harness
Custom wire harness
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
S | M | L | XL | |
---|---|---|---|---|
Crank Length | 170mm | 170mm | 170mm | 170mm |
Handlebar Width | 720mm | 750mm | 750mm | 750mm |
Stem Length | 60mm | 60mm | 70mm | 70mm |
Saddle Width | 155mm | 155mm | 155mm | 155mm |
Seatpost Length | 300mm | 400mm | 400mm | 400mm |
Stack | 637mm | 651mm | 664mm | 687mm |
Reach | 405mm | 426mm | 446mm | 462mm |
Headtube Length | 135mm | 150mm | 165mm | 190mm |
Headtube Angle | 66.4° | 66.4° | 66.4° | 66.4° |
BB Height | 313mm | 313mm | 313mm | 313mm |
BB Drop | 57mm | 57mm | 57mm | 57mm |
Trail | 114mm | 114mm | 114mm | 114mm |
Fork Length (full) | 516mm | 516mm | 516mm | 516mm |
Fork Rake/Offset | 44mm | 44mm | 44mm | 44mm |
Front Center | 709mm | 736mm | 761mm | 787mm |
Chainstay Length | 470.4mm | 470.4mm | 470.4mm | 470.4mm |
Wheelbase | 1173mm | 1200mm | 1226mm | 1252mm |
Toptube Length (horizontal) | 589mm | 620mm | 650mm | 680mm |
Bike Standover Height | 773mm | 807mm | 807mm | 835mm |
Seat Tube Length | 400mm | 450mm | 460mm | 500mm |
Seat Tube Angle (Virtual) | 73.9° | 73.4° | 72.9° | 72.4° |
Size Guide
-
